    1×1 Mechanical Fiber Optical Switch CE FCC ROHS certificated

    Ask Lasest Price
    Brand Name : SPACECOM or OEM
    Model Number : 1*1-D-5L-SM-025-15-00
    Certification : CE, FCC, ROHS, TUV, ISO9001
    Price : Get latest price
    Payment Terms : T/T, WU, PayPal, Moneygram, L/C, Western Union
    Supply Ability : 10,000pcs per week
    Delivery Time : 3-7 working days
    • Product Details
    • Company Profile

    1×1 Mechanical Fiber Optical Switch CE FCC ROHS certificated

    1×1 Mechanical Optical Switch

    Product Description

    Features

    • Compact Size
    • Fast Switching Time
    • Low Insertion Loss
    • High Reliability and stability

    Applications

    • PON Network
    • Protection
    • Network Monitoring
    • Instrumentation

    Specifications


    Parameters Unit FSW 1×1
    Working Wavelengthnm1260~1620 for SM, 850/1310 for MM

    Insertion Loss

    dB

    ≤0.5 (A Grade

    ≤0.3 (P Grade)

    WDLdB≤0.25
    TDLdB≤0.2
    PDLdB≤0.05
    Return LossdBSM≥50, MM≥30
    CrosstalkdBSM≥55, MM≥35
    RepeatabilitydB≤±0.02
    Switching Timems≤8
    Durabilitytimes≥107
    Operating VoltageV3.0 or 5.0
    Input Optical PowermW≤500
    Operating Temp.°C-5 ~ +70
    Storage Temp.°C-40 ~ +85
    Operating humidity%5 ~ 95
    DimensionmmL27×W12×H8.2 (±0.2)
